AP CG 610 Epoxy Resin Glue

Strong for small crystals.


CG 610 is a 2C epoxy resin and specially developed for bonding small crystals. The Swarovski crystal sizes PP0 to PP14 are ideally suited. CG 610 has optimal adhesion properties when bonding to metal, glass, crystal, bondable plastic, rubber, wood, cork and porcelain. Due to its low viscosity, even small quantities can be applied very easily. Compared to CG 500, the adhesive is thinner and is slightly more stable when cured. Special properties of the adhesive are its chemical resistance to perspiration, perfume and moisture, as well as strong adhesion and impact-resistant mechanical properties. The product is completely non-toxic and is not a dangerous good.

Rely on over 10 years of application experience in industry and DIY.

Technical data:

Mixing ratio
100 : 50 (volume)
Mixing ratio100 : 48 (weight)
Viscosity (mixture)1.750 ± 250 mPa*s
Pot life 23°C140 min


Handling stability 23°C
24 h
Curing time 23°C72 h
Curing time 40°C18 h
Curing time 100°C1,5 h

Scope of delivery:

50 mL adhesive catridge (16,7 mL hardener & 33,3 mL epoxy resin), 2 mixing tubes

Application



1. Check surface tension
Before starting the application of the adhesive, the suitability of the surface needs to be checked. The required surface tension measurement can be carried out very easily with our Test Pen.


2. Preparing the gluing area:
For a perfect bonding result, the gluing area has to be grain- and dust-free. Therefore, clean the surface with e.g. acetone or isopropanol before application.


3. Mix the adhesive:
Remove the cartridge cap, put on the mixing tube and insert the plunger for the cartridge. The first drop that comes out of the mixing tube should not be used, as the components may not be perfectly mixed yet. The adhesive can be applied with e.g. a spatula or with the tip of the catridge now.

4. Dosage of the adhesive:

Respective of the shape of the gluing area, the glue should be applied as follows:

With a round gluing area, a dot of glue in the center is sufficient. When the crystal is applied, the glue will be evenly distributed in the gluing gap. To glue a single spot, aim the dispensing needle just above the spot to be glued and lift it slowly upwards to avoid any glue spreading out sideways.
With a square or rectangular gluing area, apply a cross of glue to ensure it is evenly spread into the corners.

5. Remove excess adhesive:

After the bonding process, the excess adhesive can be easily removed with a cotton swab soaked in a solvent (e.g. isopropanol).



Further application instructions can be found in the Swarovski Application Manual




The data given are typical average values or characteristic values determined and measured under laboratory conditions. Therefore, the data and information given do not constitute a guarantee or assurance of specific product properties or the suitability of the product for a specific application.

Hazard and Precautionary Statements

Hazard Statements (H Phrases):
H315: Causes skin irritation.
H317: May cause an allergic skin reaction.
H318: Causes serious eye damage.
H319: Causes serious eye irritation.

Precautionary Statements (P Phrases):
P261: Avoid breathing dust / fume / gas / mist / vapours / spray.
P272: Contaminated work clothing should not be allowed out of the workplace.
P273: Avoid release to the environment.
P280: Wear protective gloves / protective clothing / eye protection / face protection.
P302+P352: IF ON SKIN: Wash with plenty of water and soap.
P305+P351+P338: IF IN EYES: Rinse cautiously with water for several minutes. Remove contact lenses, if present and easy to do. Continue rinsing.
P310: Immediately call a POISON CENTER or doctor.
P332+P313: If skin irritation occurs: Get medical advice / attention.
P333+P313: If skin irritation or rash occurs: Get medical advice / attention.
P337+P313: If eye irritation persists: Get medical advice / attention.
P362: Take off contaminated clothing.
P363: Wash contaminated clothing before reuse.
P501: Dispose of contents/container in accordance with local regulations.



Signal Word: Danger!


Hazard warning 1Hazard warning 2
